Description
The Type-X EVO light bar brings the EVO driving-light styling to a 22″ bar. A combo beam with 20,000 tested lumens reaches 1 lux at 960m, and the interchangeable orange and charcoal fascias match the EVO lights.
What’s in the kit
- 1 × 22″ STEDI EVO LED light bar
- STEDI black-out cover
- Orange fascia and charcoal grey fascia
- STEDI smart harness
- Side brackets and installation hardware
- User manual
Specifications
| LEDs | 36 × Cree XPP |
|---|---|
| Tested lumens | 20,000lm |
| 1 lux at | 960m |
| Beam | Combo (flood and spot) |
| Power | 250W |
| Amp draw | 20.8A at 12V / 10.4A at 24V |
| Voltage | 10–30V DC |
| Colour temperature | 5000K |
| IP rating | IP68, submersible to 3m |
| Weight | 6.44kg |
Fitment
Want them wired in? We fit lighting at our Cape Town workshop. Ask us for a quote. Ask us for a fitment quote.
